DJI Inspire 1 Pro Quadcopter with Zenmuse X5 4K Camera
DJI Inspire 1 Pro Quadcopter di lengkapi dengan Kamera X5 Zenmuse bersensor CMOS Micro Four Thirds yang menghasilkan Video dengan resolusi 4K. Sistem Gimbal nya mampu membawa Lensa 15mm F / 1,7. DJI Inspire 1 Pro bisa merekam dengan pandangan yang sangat luas tanpa terhalang oleh kaki kaki quadcopter, karena pada saat terbang kaki tersebut akan terangkat keatas.
solusi jika drone tidak bisa record video atau take photo
instal ulang/ganti gadget
ganti memory card / switch memory (dari internal ke external) menghindari salah satu penuh.
reset kamera setting
clear cache
Spesifikasi DJI Inspire 1 Pro
Performance
Hovering Accuracy (GPS Mode)
Vertical: 1.6′ / 0.5 m
Horizontal: 8.2′ / 2.5 m
Maximum Angular Velocity
Pitch: 300°/s
Yaw: 150°/s
Maximum Tilt Angle
35°/s
Maximum Ascent/Descent Speed
Ascent: 16.4 fps / 5 m/s
Descent: 13.1 fps / 4 m/s
Maximum Speed
72.2 fps / 22 m/s (Attitude mode; no wind)
Maximum Flight Altitude
14,764′ / 4,500 m
Maximum Wind Speed Resistance
32.8 fps / 10 m/s
Maximum Flight Time
Up to 18 minutes
Camera
Model
Name: Zenmuse X5
Lens Mount
MFT (Micro Four Thirds)
Photo Resolution
16 MP (4608 x 3456)
Video Resolution
DCI 4K (4096 x 2160): 24p, 25p
UHD 4K (3840 x 2160): 25p, 30p
FHD (1920 x 1080): 24p, 25p, 30p, 48p, 50p, 60p
Single shot
Burst: 3, 5, or 7 frames
Auto Exposure (AE) Bracketing: 3/5 bracketed frames at 0.7 EV bias
Time-Lapse: 3, 5, 7, 10, 20, 30, or 60 second intervals
With Standard Lens, Balancing Ring, Lens Hood, and microSD card: 1.2 lb / 526 g
Lens
Model
DJI MFT 15mm f/1.7 ASPH
Mount
MFT (Micro Four Thirds)
Focal Length
15 mm
35mm Equivalent: 30 mm
Aperture Range
f/1.7 to f/16
Focus Range
0.7′ (0.2 m) to ∞
Field of View
72°
Elements
9 elements in 7 groups (3 aspherical elements)
Aperture
7 diaphragm blades / circular aperture diaphragm
Dimensions
Maximum Diameter: 2.3″ / 57.5 mm
Length: 1.4″ / 36 mm
Weight
4.1 oz / 115 g
Gimbal
Model
Zenmuse X5
Mount
Detachable
Number of Axes
3-axis
Control Angle Accuracy
±0.02°
Control Range
Pitch: -90° to +30°
Pan: ±320°
Manual Control Speed
Pitch: Up to 120°/second
Pan: Up to 180°/second
Flight Controller
Indoor Hovering
Enabled by default
Vision Positioning
Frequency: 50 Hz
Velocity Range: Below 26.2 fps / 8 m/s (6.6′ / 2 m above the ground)
Altitude Range: 2 to 196.8″ / 5 to 500 cmOperating Environment: Rich pattern surface with adequate lighting (> 15 lux)
Operating Range: 0 to 8.2′ / 0 to 2.5 m
Motor
Model
DJI 3510
Propeller
Model
DJI 1345
Transmitter
Operating Frequency
Transmitter to Transmitter: 5.728 to 5.850 GHz
Transmitter to Aircraft: 2.400 to 2.483 GHz
Range
Line-of-Sight: Up to 6561.7′ / 2000 m
Receive Sensitivity
1% PER:-93 dBm
EIRP
10 dBm at 900M; 8 dBm at 5.8G; 20 dBm at 2.4G
Connectivity
1 x USB type A female (for connecting mobile device)
1 x Micro-USB for firmware updates
1 x Mini-HDMI video output for FPV
1 x CAN-Bus port (for future accessory)
Dual User Capability
Host-and-slave connection
Mobile Device Holder
Tablet or smartphone
Output Power
9 W
Power Requirements
1.2 A at 7.4 VDC
Battery
6S LiPi; 6000 mAh
Charging Temperature
Less than 3 Months: -4 to 113°F / -20 to 45°C
More than Three Months: 72 to 82°F / 22 to 28°C
Storage Temperature
72 to 82°F / 22 to 28°C -4°F / -20°C
Mobile Device Holder
Device Width: 2 to 6.7″ / 5 to 17 cm
Flight Battery
Model
TB47
Voltage
6S LiPo; 22.2 VDC
Capacity
4500 mAh / 99.9 Wh
Maximum Charging Power
180 W
Operating Temperature
-4 to 104°F / -20 to 40°C
Storage Temperature
-4 to 113°F / -20 to 45°C
72 to 82°F / 22 to 28°C
Charging Temperature
32 to 104°F / 0 to 40°C
Weight
1.3 lb / 570 g
Charger
Model
A14-100P1A
Voltage
26.3 VDC
Output Power
100 W
Mobile App
System Requirements
iOS: 7.1 or later
Android: 4.1.2 or laterNote: The device must be connected to a transmitter via USB (wireless linking is not supporting). Additionally, waypoint navigation requires an active Internet connection in order to load the maps
General
Model
Aircraft: T600
Operating Temperature
14 to 104°F / -10 to 40°C
Dimensions
Diagonal Distance:
Landing Gear Lowered: 22″ / 559 mm
Landing Gear Raised: 22.9″ / 581 mmOverall Dimensions:
17.2 x 17.8 x 11.9″ / 438 x 451 x 301 mm
